Horizontal Impact Crusher | HHI

Engineering & Technological Description

The HAZEMAG HHI Horizontal Impact Crusher introduces a revolutionary, deflection-free horizontal material flow concept. Unlike traditional vertical-feed crushers, the HHI integrates a massive heavy-duty chain conveyor directly beneath the rotating impact roll. This unique, low-profile configuration eliminates the need for tall vertical structures, making it the ideal primary crushing solution for height-restricted underground mines, tunnels, and retrofits into existing processing plants.

Technological Benefits & Engineering Value

· Ultra-Low Profile Footprint: Eliminates expensive high-rise steel structures and complex civil engineering support foundations.

· Clog-Free Deflectionless Flow: Direct horizontal feed prevents material bridging and sticky material accumulation within the crushing chamber.

· Highly Integrated Energy Efficiency: Combines the mechanical conveying and crushing functions into a single drive train, optimizing energy draw.

· Extreme Material Handling: Highly durable wear-resistant components handle steel-reinforced concrete, tough demolition waste, and abrasive rock with ease.

Heavy Industry End-Use Applications

[1] Height-Restricted Underground Mining: Performing primary crushing of minerals and ores directly within tight underground mine galleries with low ceilings.

[2] Reinforced Concrete & Asphalt Recycling: Crushing pavement slabs, demolition debris, and long reinforced concrete beams without the risk of wire entanglement.

[3] Mobile & Track-Mounted Stations: Seamless integration on track-mounted or rail-bound platforms as part of a continuous, high-mobility material handling chain.
